RF1350 - Mobile set
This mobile set with maximal adjustable output power of 50 W can be installed in all wheeled and tracked vehicles. By adding the AF13 co-site filter to the set, we made it possible to simultaneously operate more mobile sets in one vehicle. The filter tunes automatically when the frequency of the set is changed. If the mobile set is designed for installation in wheel vehicles without artillery or mortar weaponry, or for fixed posts, you may use the lighter, non-cushioned frame 7007.100.30 instead of springcushion frame 7007.100.20. All components of the set are installed in a springcushion frame. Technical parameters of the set are identical with 2011.041.61 mobile set.
| Návod k obsluze RF13 | 2000.010.01 |
|---|---|
| Krátký návod k obsluze RF13 | 2000.011.01 |
| Návod k obsluze RF1350 | 2011.010.01 |
| Krátký návod k obsluze RF1350 | 2011.011.01 |
| Záznamník | 6000002011 |
| Technický list | 6000002021 |
RF1350 - Mobile set
This mobile set with maximal output power of 50 W can be installed in all wheeled and tracked vehicles. The...
RF1350 - Mobile set
This mobile set with maximal adjustable output power of 50 W can be installed in all wheeled and tracked vehicles...
| Type designation | Name | PN (RN) | KCM | NSN |
|---|---|---|---|---|
| RF1350 | Mobile set | 2011.041.11 | ||
| RF1350 | Mobile set | 2011.041.21 |
RF13 - Transceiver
Radiostanice RF13 s vestavěným maskovačem řeči je přenosná VKV radiostanice, určená pro spojení na taktickém stupni velení.
ZV13.1 - Power amplifier 50 W (Net)
RF power amplifier for RF13 transceivers. ZV13.1 amplifier includes a high speed data modem with GMSK modulation and 16...
AF13 - Co-site filter
The AF13 filter decreases mutual interference between two VHF transceivers operating with antennas close to each other, for instance, in...
Frame
The frame is used for fixing two components of the mobile set to each other, or for installing a satellite...
Frame
CD for modem configuration
ModEx (Modem Expert) application is a universal configuration tool for setting up of network radio modems (compatible with MIL-STD188-220). ModEx...
| Type designation | Name | PN (RN) | KCM | NSN |
|---|---|---|---|---|
| RF13 | Transceiver | 2000.100.02 | 0061600202216 | 5820160015663 |
| ZV13.1 | Power amplifier 50 W (Net) | 2011.100.51 | 0068600200219 | 5996160039135 |
| AF13 | Co-site filter | 2028.100.01 | 0064241004021 | 5895160038170 |
| RF cable | 1050.401.01 | 0064301010607 | 5995160038172 | |
| RF cable | 2010.900.01 | 0064301010498 | 5995160024752 | |
| Frame | 7007.100.50 | 0064662200747 | 5975160034637 | |
| Frame | 7007.100.20 | 0064662200792 | 5975160034638 | |
| AF cable | 1050.601.02 | 0064301010614 | 5995160038171 | |
| AF cable | 1050.605.01 | 0064301010638 | 5995160038174 | |
| Grounding | 1050.993.02 | 0064301010520 | 5995160034136 | |
| Grounding | 1050.993.03 | 0064301010537 | 5995160034137 | |
| Grounding | 1050.993.05 | 0064301010544 | 5995160034138 | |
| Connector nut | 2000.475.01 | 0064661601312 | 5935160038320 | |
| CD for modem configuration | 2025.500.51 | |||
| Grounding | 1050.993.04 | 0064301010892 | 5995160034139 | |
| AF cable | 2010.901.02 | 0064301010715 | 5995160034223 | |
| RF cable | 2010.900.02 | 0064301010708 | 5995160034222 |
